Gantry Submerged Arc Welding Machine Automatic Beam Welding Line Machine

Product Categories

Wuhan Bomeda Machinery Equipment Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Payment Terms : L/C,D/P,T/T

Usage : welding H/I beam profile workpiece

Brand Name : KingCutting

Name : Submerged Arc Welding Machine

Packaging Details : wooden case

Model Number : KCW-H beam welding

Model : KCW-H beam welding

MOQ : 1

Delivery Time : 20-25days

Welding wire size : 4-5mm

Place of Origin : Wuhan

H-beam flange size 200-800mm or customized : 200-800mm or customized

Price : Negotiable

Workpiece length : 150-2000mm

Supply Ability : 10 sets/Month

Warranty : 1 year

Certification : CE, ISO9001

H-beam web size : 200-3000mm or customized

Contact Now

Gantry Submerged Arc Welding Machine Automatic Welder H Beam Automatic Production Line H beam Welding Machine

This welder serves as dedicated machinery for T‑beam and H‑beam profile welding. It can greatly boost manufacturing output, cut down capital expenditure on machinery and occupy less floor area, making it an ideal unit for high‑volume fabrication of H‑shaped and T‑shaped steel components.
Furthermore, fitted with CNC program‑based control, the unit can perform auto‑loading, self‑centering operation and robotic welding throughout the T/H beam fabrication workflow. It drastically lowers labor input and lays a firm groundwork for full‑scale automated profile manufacturing.

Model	KCW-H beam welding
Voltage	3 Phase 380V 50/60 Hz
H-beam web size	200-3000mm or customized
H-beam flange size	200-800mm or customized
Welding speed	0.25-0.8(m/min)
Welding wire size	4-5mm
Workpiece length	150-2000mm
Automatic grade	Semi-automatic
Rated capacity	20KW
H-beam Web thickness	6-80mm
H-beam Flange thickness	6-80mm
H-beam length	3000-18000mm or customized
Welding material	carbon and stainless steel
Welding angle height	hf=4-8mm
Submerged arc welding machine power	about 100kw x 2
Usage	welding H/I beam profile workpiece
Warranty	1 year

Gantry Submerged Arc Welding Machine Automatic Beam Welding Line Machine
