Desktop CNC Table Type Plasma Cutting Machine 220V For Metal Sheet

Product Categories

Wuhan Bomeda Machinery Equipment Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Model Number : KCP-T

Model : KCP-T,Table

MOQ : 1

Delivery Time : 7-15 days

Core components : Bearing, Pump, Gear, motor, Gearbox, PLC, Pressure vessel, Engine

Warranty : 18 months

Payment Terms : L/C,T/T,D/P

Software : Fastcam or Starfire

Packaging Details : wooden case

Brand Name : KingCutting

Name : Table Type Plasma Cutting Machine

Price : Negotiable

Working table : sawtooth metal working table with universal balls,clamping device

Supply Ability : 50 sets/Month

Application : Metal, Carbon Steel, Aluminium, Copper

Certification : CE, ISO9001

Cutting mode : Plasma and oxyfuel

Place of Origin : Wuhan

Cnc system : Fangling F2300B or Starfire(10.4" LCD display)

Contact Now

Desktop CNC table‑type plasma cutting machine for metal sheet

Our bench‑mounted cutter offers standalone plasma, standalone oxy‑fuel, or integrated plasma‑oxy‑fuel cutting capability. Featuring a bench‑constructed body, the Y‑axis is powered by a dual‑motor dual‑drive setup. X, Y, Z axes are all equipped with twin linear guide rails to guarantee fluent machine movement and high‑precision cutting results.
Clean, narrow kerfs eliminate the need for post‑cut secondary trimming.
It processes a wide range of metal sheets including iron, aluminum, galvanized and hardened steel plate.
The high‑grade CNC controller enables automatic arc striking and delivers dependable long‑run performance.
Supported software includes Wentai, Australia‑origin Fastcam, German IBE and FreeCAM. Besides exporting standard G‑code, the system reads DXF drawings generated by AutoCAD.
Users can transfer cutting programs easily using a USB memory stick.

Model	KCP-T,Table
Cutting size	13002500mm/15003000mm
Lifting travel	≤180mm
Input voltage	220V±10%,50/60Hz
Application	Metal, Carbon Steel, Aluminium, Copper
Cnc System	Fangling F2300B or Starfire(10.4" LCD display)
Cutting mode	Plasma and oxyfuel
Oxyfuel cutting thickness	6-180mm (carbon steel)
Plasma cutting thickness	according to plasma source
Cutting speed	0-6000m/min
Running accurancy	≤0.1mm
Motor	Mige brand(china made stepper)
Core components	Bearing, Pump, Gear, motor, Gearbox, PLC, Pressure vessel, Engine
Working table	sawtooth metal working table with universal balls,clamping device
USB interface	U-disk file transfer available
Software	Standard Fastcam or starfire

Desktop CNC Table Type Plasma Cutting Machine 220V For Metal Sheet
