Model Number : KCP-P

Model : KCP-P,Intersection pipe

MOQ : 1

Delivery Time : 15-20days

Effective cutting pipe length : 6-12m

Warranty : 2 Years

Payment Terms : L/C,T/T,D/P

Cutting torch radial direction swing angle : β=±45°

Packaging Details : wooden case

Brand Name : KingCutting

Name : CNC Pipe Plasma Cutter

Place of Origin : Wuhan

Plasma cutting pipe thickness : δ1=1～12mm (200A)

Price : Negotiable

Cutting torch axial direction swing angle : α=±45°

Certification : CE, ISO9001

Pipe diameter : Φ=60～600mm，100-1000mm (customized)

Supply Ability : 8 sets/Month

Motor : Japan servo

Contact Now

Multi‑Axis CNC Pipe Plasma Cutter For Metal Tube

This 5‑axis automatic CNC plasma machine delivers beveling and intersecting cutting for industrial metal tubes. As dedicated CNC equipment, this automatic pipe profile cutter processes metal pipes in fully‑automated mode.
It supports automatic programming and CNC nesting for complex tube‑to‑tube and pipe joint structures, completing multi‑shape cutting in a single pass.
Widely adopted in steel‑structure, shipbuilding, bridge and heavy‑machinery sectors, it handles cylinder branch cuts plus two‑layer and three‑layer saddle cuts on main pipes.
Well‑suited for high‑volume professional intersecting pipe cutting tasks.
It works on low‑carbon steel, stainless steel and non‑ferrous metals; customized machine designs are available to satisfy varied client requirements.

Model	KCP-P,Intersection pipe
Pipe diameter	Φ=60～600mm,100-1000mm (customized)
Plasma cutting pipe thickness	δ1=1～12mm (200A)
Effective cutting pipe length	6-12m
Pipe ovality	≤1%
Cutting speed	10～2000mm/min
Translational speed	10～6000 mm/min
Cutting torch axial direction swing angle	α=±45°
Cutting torch radial direction swing angle	β=±45°
Max pipe loading	2000Kgs
Motor	Japan servo
Gearbox	SEW gearbox
Driver	Japan servo motors
CNC control system	Fangling FL6400V2
Number of axis	5 axis
Working temperature	45℃
Humidity	<90%, no condenstion
Suroundings	Ventilation, no big shake
Warranty	2 years
